Quick Answer
The core of a bubble tea shop floor plan is a one-way workflow: order → make → seal → pick up, so people and cups never cross at peak time. A 33 m² takeaway shop puts ordering and pick-up at opposite ends of the counter with back-of-house along the wall; a 66 m² dine-in shop keeps the main aisle at least 120 cm and 90 cm between tables; a 20 m² mall kiosk uses a U-shaped worktop with staff entering from the back. Keep the aisle inside the bar at 90–100 cm so two people can pass.
5 layout principles
- Ordering faces the door: customers see the menu first and order faster.
- Separate ordering and pick-up: the pick-up point at the other end keeps the queue away from the door.
- Sealing next to pick-up: seal and hand off without turning back.
- Heavy equipment against the wall: tea brewing, ice, fridges and sinks along the back wall for easy plumbing and exhaust.
- A staff entrance: a counter flap or small door about 80 cm wide at one end.
Three shop types
| Shop type | Layout | Aisles |
|---|---|---|
| 33 m² takeaway | Counter across the front, ordering left and pick-up right; tea brewing, chilled storage, storage and washing on the back wall | Bar 90–100 cm; customer area 120 cm |
| 66 m² dine-in | Bar at the back, about 16 seats in front; restroom reachable directly from the customer area | Main aisle 120 cm+, between tables 90 cm+ |
| 20 m² mall kiosk | U-shaped worktop, ordering and pick-up at the two front corners; queue in front of the kiosk | Work aisle 90–100 cm; keep the mall walkway clear |
Aisle widths and ergonomics
- Bar aisle 90–100 cm: two staff can pass, even with a fridge door open.
- Worktop height 85–90 cm: no bending to shake or seal.
- Everyday items between waist and shoulder height: top shelves within reach.
- Main customer aisle 120 cm+: queueing and walking in don’t clash, and wheelchairs can pass.
- Clear door swings: entrance, staff room and restroom doors must not hit equipment or seats.
Common layout mistakes
- The counter runs wall to wall with no staff entrance.
- The aisle to the staff room or back door is blocked by sinks or tall cabinets.
- Window seats pushed against the glass, so chairs can’t pull out.
- The ice machine placed where there is no drain, needing pipes added later.
Drawings you need besides the floor plan
Before construction you also need a 3D view for heights and sightlines, a section for worktop and cabinet heights, a bar elevation for equipment positions, and utility drawings. For bar details see bubble tea bar counter design; for specs see the equipment list.
How Tang Sugar helps
Tang Sugar’s hardware planning team draws the floor plan, 3D view, section and bar drawings from your shop dimensions, menu and target volume, with utility drawings; on-site measuring and construction are done by you or a local contractor. See all three shop types on our shop opening page and request fully dimensioned drawings.
Products in this article
All 483 Bubble Tea & Boba Ingredients →
FAQ
Is 33 m² (10 ping) enough for a bubble tea shop?
Yes. It is a common takeaway size; the key is separating ordering and pick-up and keeping a one-way bar workflow.
How wide should the aisle behind the bar be?
About 90–100 cm clear, so two people can pass and fridge doors can open.
How should seats be arranged in a dine-in shop?
Leave at least 90 cm between tables and 120 cm+ for the main aisle, and keep window seats away from the glass.
What should I check for a mall kiosk?
Check the mall’s power, drainage and fit-out rules first, and keep the queue out of the public walkway.
